Electronic Cabinet Lock With Status and LED
MA1215S-T
Features:
§ Available in 12VDC or 24VDC
§ Superior heavy duty metal construction
§ Chrome-plated steel housing (rust-resistant)
§ Convenient mechanical override enables manually release during power failure
§ Three-bolt regular triangle mounting enables high security and low install cost
§ Accepts access control signals from numeric keypad, RFID card, remote or fingerprint
§ Can be fitted to Cabinets, lockers, drawers and steel furniture etc
§ Patented Design
§ 2 years limited warranty
Specification:
|
Operation Voltage |
12/24VDC intermittent ±10% |
|
Power Consumption |
12V DC 800mA |
|
Operation Mode |
Fail Locked |
|
Holding Force |
200KG |
|
Maximum power on time |
Less than 30 second |
|
Solenoid |
Rated for intermittence use |
|
Cycle Rating |
More than 1,000,000 times |
|
Mechanical Override |
7mm hole |
|
Working Temperature |
-20ºC ~ +60ºC |
|
Dimensions LxWxH |
72mm*56mm*13.8mm |
|
Gross Weight |
250g |
|
Protection Class |
IP20 |
|
Compliance |
CE and RoHs certificate |
Part No.
|
Model no. |
Operation current |
Status |
Push strength |
LED light |
Mechanical override |
|
MA1208 |
12VDC 800mA |
Without |
4N or 7N |
Without |
Hidden |
|
MA1208S |
12VDC 800mA |
With |
4N or 7N |
Without |
Hidden |
|
MA1208L |
12VDC 800mA |
Without |
4N or 7N |
Without |
Exposed |
|
MA1208LS |
12VDC 800mA |
With |
4N or 7N |
Without |
Exposed |
|
MA1215 |
12VDC 1500mA |
Without |
15N or 21N |
Without |
Hidden |
|
MA1215S |
12VDC 1500mA |
With |
15N or 21N |
Without |
Hidden |
|
MA1215L |
12VDC 1500mA |
Without |
15N or 21N |
Without |
Exposed |
|
MA1215LS |
12VDC 1500mA |
With |
15N or 21N |
Without |
Exposed |
|
MA1208-T |
12VDC 800mA |
Without |
4N or 7N |
With |
Hidden |
|
MA1208S-T |
12VDC 800mA |
With |
4N or 7N |
With |
Hidden |
|
MA1208L-T |
12VDC 800mA |
Without |
4N or 7N |
With |
Exposed |
|
MA1208LS-T |
12VDC 800mA |
With |
4N or 7N |
With |
Exposed |
|
MA1215-T |
12VDC 1500mA |
Without |
15N or 21N |
With |
Hidden |
|
MA1215S-T |
12VDC 1500mA |
With |
15N or 21N |
With |
Hidden |
|
MA1215L-T |
12VDC 1500mA |
Without |
15N or 21N |
With |
Exposed |
|
MA1215LS-T |
12VDC 1500mA |
With |
15N or 21N |
With |
Exposed |
We offer customization for cable length and connector type to meet the exact requirement of your application.
Application
Vending machine
Electronic locker
Van door
Gun or weapon cabinets
Bike or scooter station
Utility cabinets and drawers
Museum display cases
