Combination Cam Lock MB4311 is a combination lock used for secure drawer and cabinet. The combination lock is featured by 10000 possible combinations and resettable codes. It consists of three numbers that must be entered by manipulating a dial in specific sequence. The lock cam can be rotated to be clockwise or counter clockwise. Master key allows emergency open.

Features

Ÿ   Plastic Construction

Ÿ   4 dial digit combination, secure and easy to use.

Ÿ   10000 possible code combinations

Ÿ   Codes easily resettable

Ÿ   Master Key Override for Emergency

Ÿ   Cam can be rotate clockwise or counter clockwise.

The Combination cabinet lock is ideal for various applications as following:

Metal cabinet or steel furniture

Retail display cases and drawers

Filing cabinets

Utility cabinets and drawers

Museum display cases

Pharmaceutical cabinets and drawers

Quick Guide:

Code Setting

The default code is 0000 and please reset the code as the following steps:

Insert Key and turn the knob pointing to OPEN

Rotate the 4 dials to the desired combination in the middle of the keypad.

Turn the Knob pointing to CLOSE

Unlock the door

Dial the 4 digit code

Turn knob pointing to OPEN

Help with Forgotten or Lost Lock Combinations

Unlock the door with master key

Turn the knob pointing to lock arrow and remove the key

Insert the master key and turn it 180 degree

Rotate the dial until it stops, the number in the middle is the code

Then use the same way to get back the rest three numbers.

Turn the master key back 180 degree

The mounting hole is 73.4*20.3mm

Hint:

Consider writing the new code combination down and keep it in a safe place in case you forget the combination.

Spin the dial of the lock after opening to preventing code exposure.
