Features

Ÿ   ABS plastic Construction

Ÿ   3 dial digit combination, secure and easy to use.

Ÿ   1000 possible code combinations

Ÿ   Codes easily resettable

Ÿ   Cam can be rotate clockwise or counter clockwise.

Ÿ   Suitable for metal cabinet door thickness 1.1mm

Applications:

The Combination cabinet lock is ideal for various applications as following:

Metal cabinet or steel furniture

Retail display cases and drawers

Filing cabinets

Utility cabinets and drawers

Museum display cases

Pharmaceutical cabinets and drawers

Quick Guide:

Code Setting

The default code is 000 and please reset the code as the following steps:

Push the reset button on the back of the lock body

Rotate the 3 dials to the desired combination in the middle of the keypad.

Pull the reset button back

Unlock the door

Dial the 3 digit code

Rotate the knob to open the door

The mounting hole is 61.5*26mm

Hint:

Consider writing the new code combination down and keep it in a safe place in case you forget the combination.

Spin the dial of the lock after opening to preventing code exposure.
