Stainless Steel Keypad for Kiosk KP1016 is a 16 keys compact keypad for various applications of terminals. It is featured by IP65 dynamic vandal proof Stainless Steel encryption PINPAD with industrial encryption electronics controller supporting DES/TDES shielded & protected by stainless steel housing. With gold-on-gold key switch technology, the keypad provides long stroke with extremely good tactile feeling for fast and accurate data input without any noise.

Features

§  Stainless steel fascia and key-tops guard willful destruction, against corrosion, shock, dust, failing raining, splashing, hose-directed water and vandal resistant, operation under hostile environments.

§  Laser engraved characters for excellent durable

§  With gold-on-gold key contact with long stroke, with unique double over-travel protection.

§  Waterproof/dirt-proof execution according to degree of protection IP65.

§  Easily mounting into enclosure or panel, and is provided with PS/2, or USB, RS232, connection output cables that plug directly into the host computer for normal keypad operations.

§  OS: Windows 95/98/NT/ME/2000/2003/XP/Vista/WIN7, Linux, Unix,

§  Any language is available for customization

Communication parameter

USB, PS2 or RS232 are all available

16 actuator on the keypad: 0,1,2,3,4,5,6,7,8,9, EXIT, P-UP, P-DOWN, ENTER, CLEAR, 4X4 scanning code. Any keys can be re-defined per customer’s requirements.

Specification:

Application:

This keyboard is mainly use for unattended internet terminals and information kiosks in public areas, parcel delivery lockers, electronic lockers, self-service terminals in bank, ticket vending machines, gas stations, cash machines, etc
