Electronic Rotary Latch for Vending Manchine
MD1220S-H
Features:
- Stainless steel 304 construction
- Surface-mounted compact electric lock
- Convenient mechanical override enables manual release during power failure
- Operates against heavy mechanical load
- Optional internal microswitch for latch open/close output signal
- Accepts access control signals from wireless RF key fobs or proximity cards, numeric keypads, card readers,
- Can be fitted to locker, mail box and drawers etc
Specifications:
|
Operation Voltage: |
12/24VDC intermittent ±10% |
|
Power Consumption: |
12V DC 2000mA |
|
Operation Mode: |
Fail Locked |
|
Solenoid Type: |
Intermittent |
|
Max. Power on: |
1 second |
|
Holding Force: |
600KG |
|
Cycle Rating: |
More than 1,000,000 |
|
MS Contact Rating: |
5A @125V |
|
Working Temperature: |
-20ºC ~ +60ºC |
|
Dimensions LxWxH: |
72mm*67mm*18mm |
|
Weight: |
330g |
|
Protection Class: |
IP20 |
Part No.
|
Part No |
Operating Current |
Micro switch |
Push strength |
Manual Override |
Construction |
|
MD1215 |
12VDC@1500mA |
Without |
10N/15N |
Hidden |
Steel |
|
MD1215S |
12VDC@1500mA |
With |
10N/15N |
Hidden |
Steel |
|
MD1215L |
12VDC@1500mA |
Without |
10N/15N |
Exposed |
Steel |
|
MD1215LS |
12VDC@1500mA |
With |
10N/15N |
Steel |
|
|
MD1220 |
12VDC@2000mA |
Without |
10N/25N/35N |
Hidden |
Steel |
|
MD1220S |
12VDC@2000mA |
With |
10N/25N/35N |
Hidden |
Steel |
|
MD1220L |
12VDC@2000mA |
Without |
10N/25N/35N |
Exposed |
Steel |
|
MD1220LS |
12VDC@2000mA |
With |
10N/25N/35N |
Exposed |
Steel |
|
MD1215H |
12VDC@1500mA |
Without |
10N/15N |
Hidden |
Stainless S. |
|
MD1215SH |
12VDC@1500mA |
With |
10N/15N |
Hidden |
Stainless S. |
|
MD1215LH |
12VDC@1500mA |
Without |
10N/15N |
Exposed |
Stainless S. |
|
MD1215LSH |
12VDC@1500mA |
With |
10N/15N |
Exposed |
Stainless S. |
|
MD1220H |
12VDC@2000mA |
Without |
10N/25N/35N |
Hidden |
Stainless S. |
|
MD1220SH |
12VDC@2000mA |
With |
10N/25N/35N |
Hidden |
Stainless S. |
|
MD1220LH |
12VDC@2000mA |
Without |
10N/25N/35N |
Exposed |
Stainless S. |
|
MD1220LSH |
12VDC@2000mA |
With |
10N/25N/35N |
Exposed |
Stainless S. |
|
MD1215P |
12VDC@1500mA |
Without |
10N/15N |
Hidden |
Water proof |
|
MD1215SP |
12VDC@1500mA |
With |
10N/15N |
Hidden |
Water proof |
|
MD1215LP |
12VDC@1500mA |
Without |
10N/15N |
Exposed |
Water proof |
|
MD1215LSP |
12VDC@1500mA |
With |
10N/15N |
Exposed |
Water proof |
|
MD1220P |
12VDC@2000mA |
Without |
10N/25N/35N |
Hidden |
Water proof |
|
MD1220SP |
12VDC@2000mA |
With |
10N/25N/35N |
Hidden |
Water proof |
|
MD1220LP |
12VDC@2000mA |
Without |
10N/25N/35N |
Exposed |
Water proof |
|
MD1220LSP |
12VDC@2000mA |
With |
10N/25N/35N |
Exposed |
Water proof |
We offer customization for cable length and connector type to better meet the exact requirement of your application.
Application
- Vending machine
- Electronic locker
- Van door
- Gun or weapon cabinets
- Bike or scooter station
- Utility cabinets and drawers
- Museum display cases
- Pharmaceutical cabinets and drawers
